ALTA (AIR HEATING COIL UNITS) Product Catalogue
ALTA,axial type unit heaters are used to heat big volumes like factories, workshops, hangars, garages, storage areas, gymnasiums, etc.

Asstandard,units are manufactured between 4.000 to24.000 kcal/h capacity at 90 / 70 °C hot water conditions.

As an option, ALTAaxialtype unit heaters can be manufactured to be compatible with superheated water and steam.

It is more suitable to prefer ALTA axialtype unit heaters in enclosed areas with ceiling height less than 4 m.

1. CASING
ALTA axial type unit heaters are manufactured from electrostatic powder painted galvanized sheet metal. They have a light and compact design to be installed to both wall & ceiling.

2. AXIAL FAN-MOTOR GROUP
ALTA axial type unit heaters include direct driven axial fan groups. The quiet and secure fan is powered from the 230 V 50 Hz line.

3. HEATING COIL
Copper tube aluminum finned heating coils are used in ALTA axial type unit heaters. With these high efficiency coils, the desired heat transfer can be easily achieved.

4. AIR ADJUSTMENT WINGS
Adjustable wings for directing the air stream to the desired side.

5. HEATING MEDIA INLET - OULET CONECTIONS
As standard, bolted joint connections are used for pipe connections.
Read more

KAPASİTE TABLOSU
TİP BOYUT TABLOSU (mm) Sıcak Su Baglantı Çapları Giris / Çıkıs
ALTA A B C D E F H K ø d
4 440 415 470 240 88 325 70 60 3/4"
6 440 415 470 240 88 325 70 60 3/4"
8 440 415 470 240 88 325 70 60 3/4"
10 440 415 470 240 88 325 70 60 3/4"
12 440 415 470 240 88 325 70 60 3/4"
16 440 415 470 240 88 325 70 60 3/4"
20 440 415 470 240 88 325 70 60 3/4"
24 440 415 470 240 88 325 70 60 3/4"
